AGRAS T40

Since the first day we brought this biggest and the most advanced DJI Agras T40 drone to our farm community, farmers often talks the most exciting thing about the this model may not only be its large capacity and high efficiency, but also its mapping function.

Unlike previous Agras models that required manual surveying and mapping, the T40 can fly to an altitude of 30 meters for fully autonomous high-precision surveying and mapping. The remote control has built-in software, and you can directly edit the plots you need to work on.

And the motor, you might not notice, DJI’s T40 has a 50KG dry tank but equipped with 8 pcs 4000W large motors, a total of 32000W. That means when you fly the T40 drone, you will have this redundancy system ensure your safe fly stability.

Let’s take a look at the details together!

Spreading Capability

Spraying Capability

✅Automatic-calculation system (for easy and accurate dosing)
Example: If 1 hectare requires 120kg of fertilizer, we, farmers do not need to do manual calculations and inaccurate estimation. We’ll just have to type the amount we need per hectare in on the remote controller screen and then the drone will calculate the total amount and spread as much as we’ve decided given the size of the field.

✅Equipped with “Low Speed Ascent” feature
Example: The drone will automatically adjust its flying height higher than the set operation height every time it’s changing to the next spraying lane to prevent toppling the crops.

✅ Built-in Weight Sensor
The actual weight of the material we fill in the tank will be displayed in real time on the remote controller screen.

✅Smart Spreading
Example: Spreading work for the area that we’ve plotted will be done exactly according to our presets, and the drone always knows the last point it finishes spreading material in the tank and can continue from there after refilling.

✅Empty Tank Sensor
Example: If the filled material in the tank is run out, the drone will stop spreading by itself and you will be notified through the remote controller to avoid wasting battery.

✅Wide Spreading Range
The dry tank has a horizontally rotating disc, which covers a wider area and spreads more evenly.

✅Automatic data-saving system (for each calibrated material)
Example: Fertilizers, Urea, mixtures and seeds

✅Easy tank change in 30 seconds!

No need to change nozzles (saving time)
Example: You can adjust the size of the droplets on the remote control of the T40.

No worries about clogging
Example: T40 supports the spraying of powder products.

The droplet particles are more uniform
Example: T40 adopts the dual-atomization centrifugal nozzle independently developed by DJI to conduct secondary atomization on the droplet particles. The nozzle speed range: 8000-16000r/min, and the atomization particle size: 60-500μm. Avoid damage to crop epidermis by large particle droplets.

Smart spraying system and Continue to spray at the breakpoint
Example: T40 will work exactly as you preset on the map, and the drone always knows the last point it finished spraying, after refill, it will start spraying from next line until it meets the breakpoint and complete whatever left in this line, then continue spraying the rest of the routes. so as not to waste the battery.

Spray width
Example: It can be adjusted between 12ft-33ft on the remote control of T40

Spray height
Example: Equipped with a radar system, it can fly at the height of the ground and the height of the crops, and automatically detect the distance between the drone and the top of the crops.

And more…
